The “Octad Group” as Symmetries of the 4×4 Square

Filed under: General — m759 @ 6:32 PM

From “Mathieu Moonshine and Symmetry Surfing” —

(Submitted on 29 Sep 2016, last revised 22 Jan 2018)
by Matthias R. Gaberdiel (1), Christoph A. Keller (2),
and Hynek Paul (1)

(1)  Institute for Theoretical Physics, ETH Zurich
(2)  Department of Mathematics, ETH Zurich

https://arxiv.org/abs/1609.09302v2 —

“This presentation of the symmetry groups Gi  is
particularly well-adapted for the symmetry surfing
philosophy. In particular it is straightforward to
combine them into an overarching symmetry group G
by combining all the generators. The resulting group is
the so-called octad group

G = (Z2)4  A8 .

It can be described as a maximal subgroup of M24
obtained by the setwise stabilizer of a particular
‘reference octad’ in the Golay code, which we take
to be O= {3,5,6,9,15,19,23,24} ∈ 𝒢24. The octad
subgroup is of order 322560, and its index in M24
is 759, which is precisely the number of
different reference octads one can choose.”

This “octad group” is in fact the symmetry group of the affine 4-space over GF(2),
so described in 1979 in connection not with the Golay code but with the geometry
of the 4×4 square.* Its nature as an affine group acting on the Golay code was
known long before 1979, but its description as an affine group acting on
the 4×4 square may first have been published in connection with the
Cullinane diamond theorem and Abstract 79T-A37, “Symmetry invariance in a
diamond ring
,” by Steven H. Cullinane in Notices of the American Mathematical
, February 1979, pages A-193, 194.

* The Galois tesseract .

Update of March 15, 2020 —

Conway and Sloane on the “octad group” in 1993 —

Sunday, September 8, 2019

The Child-Resistant 4×4

Filed under: General — m759 @ 7:03 AM

Thursday, June 27, 2019

Group Actions on the 4x4x4 Cube

Filed under: General — Tags: — m759 @ 6:23 AM

For affine  group actions, see Ex Fano Appollinis  (June 24)
and Solomon's Cube.

For one approach to Mathieu  group actions on a 24-cube subset
of the 4x4x4 cube, see . . .

For a different sort of Mathieu cube, see Aitchison.

Thursday, February 7, 2019

Geometry of the 4×4 Square: The Kummer Configuration

Filed under: General — Tags: , — m759 @ 12:00 AM

From the series of posts tagged Kummerhenge

A Wikipedia article relating the above 4×4 square to the work of Kummer —

A somewhat more interesting aspect of the geometry of the 4×4 square
is its relationship to the 4×6 grid underlying the Miracle Octad Generator
(MOG) of R. T. Curtis.  Hudson's 1905 classic Kummer's Quartic Surface
deals with the Kummer properties above and also foreshadows, without
explicitly describing, the finite-geometry properties of the 4×4 square as
a finite affine 4-space — properties that are of use in studying the Mathieu
group M24  with the aid of the MOG.

Tuesday, September 13, 2016

Parametrizing the 4×4 Array

Filed under: General,Geometry — Tags: , , , — m759 @ 10:00 PM

The previous post discussed the parametrization of
the 4×4 array as a vector 4-space over the 2-element
Galois field GF(2).

The 4×4 array may also be parametrized by the symbol
0  along with the fifteen 2-subsets of a 6-set, as in Hudson's
1905 classic Kummer's Quartic Surface

Hudson in 1905:

These two ways of parametrizing the 4×4 array — as a finite space
and as an array of 2-element sets —  were related to one another
by Cullinane in 1986 in describing, in connection with the Curtis
"Miracle Octad Generator,"  what turned out to be 15 of Hudson's
1905 "Göpel tetrads":

A recap by Cullinane in 2013:

IMAGE- Geometry of the Six-Set, Steven H. Cullinane, April 23, 2013

Click images for further details.

Friday, January 17, 2014

The 4×4 Relativity Problem

Filed under: General,Geometry — Tags: , , , — m759 @ 11:00 PM

The sixteen-dot square array in yesterday’s noon post suggests
the following remarks.

“This is the relativity problem:  to fix objectively a class of
equivalent coordinatizations and to ascertain the group of
transformations S mediating between them.”

— Hermann Weyl, The Classical Groups ,
Princeton University Press, 1946, p. 16

The Galois tesseract  appeared in an early form in the journal
Computer Graphics and Art , Vol. 2, No. 1, February 1977—

IMAGE- Hypercube and 4x4 matrix from the 1976 'Diamond Theory' preprint, as excerpted in 'Computer Graphics and Art'

The 1977 matrix Q is echoed in the following from 2002—

IMAGE- Dolgachev and Keum, coordinatization of the 4x4 array in 'Birational Automorphisms of Quartic Hessian Surfaces,' AMS Transactions, 2002

A different representation of Cullinane’s 1977 square model of the
16-point affine geometry over the two-element Galois field GF(2)
is supplied by Conway and Sloane in Sphere Packings, Lattices and Groups
(first published in 1988) :

IMAGE- The Galois tesseract as a four-dimensional vector space, from a diagram by Conway and Sloane in 'Sphere Packings, Lattices, and Groups'

Here a, b, c, d   are basis vectors in the vector 4-space over GF(2).
(For a 1979 version of this vector space, see AMS Abstract 79T-A37.)

See also a 2011 publication of the Mathematical Association of America —

From 'Beautiful Mathematics,' by Martin Erickson, an excerpt on the Cullinane diamond theorem (with source not mentioned)

Friday, June 12, 2020

Bullshit Studies: “Hyperseeing”

Filed under: General — m759 @ 12:13 AM

In memoriam —

Friedman co-edited the ISAMA journal  Hyperseeing .  See also . . .

See too the other articles in Volume 40 of  Kybernetes .

Related material —

Compare and contrast the discussion of the geometry
of the 4×4 square
in the diamond theorem (1976) with
Nat Friedman’s treatment of the same topic in 2001 —

Thursday, May 28, 2020

Finite Geometry at GitHub

Filed under: General — Tags: , , — m759 @ 5:04 PM

My website on finite geometry is now available
on GitHub at http://m759.github.io/ . The part
of greatest interest to coders is also at
https://repl.it/@m759/View-4x4x4#index.html .

Wednesday, February 19, 2020

Aitchison’s Octads

Filed under: General — Tags: , — m759 @ 11:36 AM

The 759 octads of the Steiner system S(5,8,24) are displayed
rather neatly in the Miracle Octad Generator of R. T. Curtis.

A March 9, 2018, construction by Iain Aitchison* pictures the
759 octads on the faces of a cube , with octad elements the
24 edges of a  cuboctahedron :

The Curtis octads are related to symmetries of the square.

See my webpage "Geometry of the 4×4 square" from March 2004.
Aitchison's p. 42 slide includes an illustration from that page —

Aitchison's  octads are instead related to symmetries of the cube.

Note that essentially the same model as Aitchison's can be pictured
by using, instead of the 24 edges of a cuboctahedron, the 24 outer
faces of subcubes in the eightfold cube .

The Eightfold Cube: The Beauty of Klein's Simple Group

   Image from Christmas Day 2005.
