Friday, November 20, 2015

Anticommuting Dirac Matrices as Skew Lines

Filed under: General,Geometry — Tags: , — m759 @ 11:45 pm

(Continued from November 13)

The work of Ron Shaw in this area, ca. 1994-1995, does not
display explicitly the correspondence between anticommutativity
in the set of Dirac matrices and skewness in a line complex of
PG(3,2), the projective 3-space over the 2-element Galois field.

Here is an explicit picture —

Anticommuting Dirac matrices as spreads of projective lines

References:

Arfken, George B., Mathematical Methods for Physicists , Third Edition,
Academic Press, 1985, pages 213-214

Cullinane, Steven H., Notes on Groups and Geometry, 1978-1986

Shaw, Ron, "Finite Geometry, Dirac Groups, and the Table of
Real Clifford Algebras," undated article at ResearchGate.net

Update of November 23:

See my post of Nov. 23 on publications by E. M. Bruins
in 1949 and 1959 on Dirac matrices and line geometry,
and on another author who gives some historical background
going back to Eddington.

Some more-recent related material from the Slovak school of
finite geometry and quantum theory —

Saniga, 'Finite Projective Spaces, Geometric Spreads of Lines and Multi-Qubits,' excerpt

The matrices underlying the Saniga paper are those of Pauli, not
those of Dirac, but these two sorts of matrices are closely related.

Friday, November 13, 2015

A Connection between the 16 Dirac Matrices and the Large Mathieu Group



Note that the six anticommuting sets of Dirac matrices listed by Arfken
correspond exactly to the six spreads in the above complex of 15 projective
lines of PG(3,2) fixed under a symplectic polarity (the diamond theorem
correlation

). As I noted in 1986, this correlation underlies the Miracle
Octad Generator of R. T. Curtis, hence also the large Mathieu group.

References:

Arfken, George B., Mathematical Methods for Physicists , Third Edition,
Academic Press, 1985, pages 213-214

Cullinane, Steven H., Notes on Groups and Geometry, 1978-1986

Related material:

The 6-set in my 1986 note above also appears in a 1996 paper on
the sixteen Dirac matrices by David M. Goodmanson —

Background reading:

Ron Shaw on finite geometry, Clifford algebras, and Dirac groups
(undated compilation of publications from roughly 1994-1995)—

Wednesday, May 25, 2016

Kummer and Dirac

From "Projective Geometry and PT-Symmetric Dirac Hamiltonian,"
Y. Jack Ng  and H. van Dam,
Physics Letters B , Volume 673, Issue 3,
23 March 2009, Pages 237–239

(http://arxiv.org/abs/0901.2579v2, last revised Feb. 20, 2009)

" Studies of spin-½ theories in the framework of projective geometry
have been undertaken before. See, e.g., Ref. [4]. 1 "

1 These papers are rather mathematical and technical.
The authors of the first two papers discuss the Dirac equation
in terms of the Plucker-Klein correspondence between lines of
a three-dimensional projective space and points of a quadric
in a five-dimensional projective space. The last paper shows
that the Dirac equation bears a certain relation to Kummer’s
surface, viz., the structure of the Dirac ring of matrices is
related to that of Kummer’s 166 configuration . . . ."

[4]

O. Veblen
Proc. Natl. Acad. Sci. USA , 19 (1933), p. 503
Full Text via CrossRef

E.M. Bruins
Proc. Nederl. Akad. Wetensch. , 52 (1949), p. 1135

F.C. Taylor Jr., Master thesis, University of North Carolina
at Chapel Hill (1968), unpublished


A remark of my own on the structure of Kummer’s 166 configuration . . . .

See that structure in this  journal, for instance —

See as well yesterday morning's post.

Monday, December 14, 2015

Dirac and Geometry

Filed under: General,Geometry — Tags: , — m759 @ 10:30 am

(Continued)

See a post by Peter Woit from Sept. 24, 2005 — Dirac's Hidden Geometry.

The connection, if any, with recent Log24 posts on Dirac and Geometry
is not immediately apparent.  Some related remarks from a novel —

From Broken Symmetries by Paul Preuss
(first published by Simon and Schuster in 1983) —

"He pondered the source of her fascination with the occult, which sooner or later seemed to entangle a lot of thoughtful people who were not already mired in establishmentarian science or religion. It was  the religious impulse, at base. Even reason itself could function as a religion, he supposed— but only for those of severely limited imagination.

He’d toyed with 'psi' himself, written a couple of papers now much quoted by crackpots, to his chagrin. The reason he and so many other theoretical physicists were suckers for the stuff was easy to understand— for two-thirds of a century an enigma had rested at the heart of theoretical physics, a contradiction, a hard kernel of paradox. Quantum theory was inextricable from the uncertainty relations.

The classical fox knows many things, but the quantum-mechanical hedgehog knows only one big thing— at a time. 'Complementarity,' Bohr had called it, a rubbery notion the great professor had stretched to include numerous pairs of opposites. Peter Slater was willing to call it absurdity, and unlike some of his older colleagues who, following in Einstein’s footsteps, demanded causal explanations for everything (at least in principle), Peter had never thirsted after 'hidden variables' to explain what could not be pictured. Mathematical relationships were enough to satisfy him, mere formal relationships which existed at all times, everywhere, at once. It was a thin nectar, but he was convinced it was the nectar of the gods.

The psychic investigators, on the other hand, demanded to know how  the mind and the psychical world were related. Through ectoplasm, perhaps? Some fifth force of nature? Extra dimensions of spacetime? All these naive explanations were on a par with the assumption that psi is propagated by a species of nonlocal hidden variables, the favored explanation of sophisticates; ignotum per ignotius

'In this connection one should particularly remember that the human language permits the construction of sentences which do not involve any consequences and which therefore have no content at all…' The words were Heisenberg’s, lecturing in 1929 on the irreducible ambiguity of the uncertainty relations. They reminded Peter of Evan Harris Walker’s ingenious theory of the psi force, a theory that assigned psi both positive and negative values in such a way that the mere presence of a skeptic in the near vicinity of a sensitive psychic investigation could force null results. Neat, Dr. Walker, thought Peter Slater— neat, and totally without content.

One had to be willing to tolerate ambiguity; one had to be willing to be crazy. Heisenberg himself was only human— he’d persuasively woven ambiguity into the fabric of the universe itself, but in that same set of 1929 lectures he’d rejected Dirac’s then-new wave equations with the remark, 'Here spontaneous transitions may occur to the states of negative energy; as these have never been observed, the theory is certainly wrong.' It was a reasonable conclusion, and that was its fault, for Dirac’s equations suggested the existence of antimatter: the first antiparticles, whose existence might never have been suspected without Dirac’s crazy results, were found less than three years later.

Those so-called crazy psychics were too sane, that was their problem— they were too stubborn to admit that the universe was already more bizarre than anything they could imagine in their wildest dreams of wizardry."

Particularly relevant

"Mathematical relationships were enough to satisfy him,
mere formal relationships which existed at all times,
everywhere, at once."

Some related pure  mathematics

Anticommuting Dirac matrices as spreads of projective lines

Monday, November 23, 2015

Dirac and Line Geometry

Some background for my post of Nov. 20,
"Anticommuting Dirac Matrices as Skew Lines" —

First page of 'Configurations in Quantum Mechanics,' by E.M. Bruins, 1959

His earlier paper that Bruins refers to, "Line Geometry
and Quantum Mechanics," is available in a free PDF.

For a biography of Bruins translated by Google, click here.

For some additional historical background going back to
Eddington, see Gary W. Gibbons, "The Kummer
Configuration and the Geometry of Majorana Spinors,"
pages 39-52 in Oziewicz et al., eds., Spinors, Twistors,
Clifford Algebras, and Quantum Deformations:
Proceedings of the Second Max Born Symposium held
near Wrocław, Poland, September 1992
 . (Springer, 2012,
originally published by Kluwer in 1993.)

For more-recent remarks on quantum geometry, see a
paper by Saniga cited in today's update to my Nov. 20 post

Wednesday, April 20, 2022

Physics for Poets

Filed under: General — Tags: , , — m759 @ 9:23 am

Excerpt from a long poem by Eliza Griswold


The square array above does not  contain Arfken's variant
labels
for ρ1, ρ2, and ρ3, although those variant labels were
included in Arfken's 1985 square array and in Arfken's 1985
list of six anticommuting sets, copied at MathWorld as above.
The omission of variant labels prevents a revised list of the
six anticommuting sets from containing more  distinct symbols
than there are matrices.

Revised list of anticommuting sets:

α1   α2   α3  ρ2  ρ3

γ1   γ2   γ3   ρ1   ρ

δ δ2   δ ρ1   ρ2

α1    γ1   δσ2  σ3

α  γ2   δσ1   σ3

α  γ3   δ3  σ1   σ2  .

Context for the poem: Quark Rock.
Context for the physics: Dirac Matrices.

Wednesday, October 9, 2019

The Joy of Six

Note that in the pictures below of the 15 two-subsets of a six-set,
the symbols 1 through 6 in Hudson's square array of 1905 occupy the
same positions as the anticommuting Dirac matrices in Arfken's 1985
square array. Similarly occupying these positions are the skew lines
within a generalized quadrangle (a line complex) inside PG(3,2).

Anticommuting Dirac matrices as spreads of projective lines

Related narrative The "Quantum Tesseract Theorem."

Friday, September 27, 2019

The Black List

Filed under: General — Tags: , , — m759 @ 11:46 am

"… Max Black, the Cornell philosopher, and others have pointed out
how 'perhaps every science must start with metaphor and end with
algebra, and perhaps without the metaphor there would never have
been any algebra' …."

— Max Black, Models and Metaphors, Cornell U. Press, 1962,
page 242, as quoted in Dramas, Fields, and Metaphors, by
Victor Witter Turner, Cornell U. Press, paperback, 1975, page 25


Metaphor —

Algebra —

The 16 Dirac matrices form six anticommuting sets of five matrices each (Arfken 1985, p. 214):

1. alpha_1alpha_2alpha_3alpha_4alpha_5,

2. y_1y_2y_3y_4y_5,

3. delta_1delta_2delta_3rho_1rho_2,

4. alpha_1y_1delta_1sigma_2sigma_3,

5. alpha_2y_2delta_2sigma_1sigma_3,

6. alpha_3y_3delta_3sigma_1sigma_2.

SEE ALSO:  Pauli Matrices

REFERENCES:

Arfken, G. Mathematical Methods for Physicists, 3rd ed.  Orlando, FL: Academic Press, pp. 211-217, 1985.

Berestetskii, V. B.; Lifshitz, E. M.; and Pitaevskii, L. P. "Algebra of Dirac Matrices." §22 in Quantum Electrodynamics, 2nd ed.  Oxford, England: Pergamon Press, pp. 80-84, 1982.

Bethe, H. A. and Salpeter, E. Quantum Mechanics of One- and Two-Electron Atoms.  New York: Plenum, pp. 47-48, 1977.

Bjorken, J. D. and Drell, S. D. Relativistic Quantum Mechanics.  New York: McGraw-Hill, 1964.

Dirac, P. A. M. Principles of Quantum Mechanics, 4th ed.  Oxford, England: Oxford University Press, 1982.

Goldstein, H. Classical Mechanics, 2nd ed.  Reading, MA: Addison-Wesley, p. 580, 1980.

Good, R. H. Jr. "Properties of Dirac Matrices." Rev. Mod. Phys. 27, 187-211, 1955.

Referenced on Wolfram|Alpha:  Dirac Matrices

CITE THIS AS:

Weisstein, Eric W.  "Dirac Matrices."

From MathWorld— A Wolfram Web Resource.
http://mathworld.wolfram.com/DiracMatrices.html

Desiring the exhilarations of changes:
The motive for metaphor, shrinking from
The weight of primary noon,
The A B C of being,

The ruddy temper, the hammer
Of red and blue, the hard sound—
Steel against intimation—the sharp flash,
The vital, arrogant, fatal, dominant X.

— Wallace Stevens, "The Motive for Metaphor"

Saturday, August 10, 2019

Schoolgirl Space* Revisited:

Filed under: General — Tags: , , — m759 @ 10:51 pm

The Square "Inscape" Model of
the Generalized Quadrangle W(2)

Click image to enlarge.

* The title refers to the role of PG (3,2) in Kirkman's schoolgirl problem.
For some backstory, see my post Anticommuting Dirac Matrices as Skew Lines
and, more generally, posts tagged Dirac and Geometry.

Sunday, July 14, 2019

Old Pathways in Science:

Filed under: General — Tags: , — m759 @ 12:37 pm

The Quantum Tesseract Theorem Revisited

From page 274 —

"The secret  is that the super-mathematician expresses by the anticommutation
of  his operators the property which the geometer conceives as  perpendicularity
of displacements.  That is why on p. 269 we singled out a pentad of anticommuting
operators, foreseeing that they would have an immediate application in describing
the property of perpendicular directions without using the traditional picture of space.
They express the property of perpendicularity without the picture of perpendicularity.

Thus far we have touched only the fringe of the structure of our set of sixteen E-operators.
Only by entering deeply into the theory of electrons could I show the whole structure
coming into evidence."

A related illustration, from posts tagged Dirac and Geometry —

Anticommuting Dirac matrices as spreads of projective lines

Compare and contrast Eddington's use of the word "perpendicular"
with a later use of the word by Saniga and Planat.

Monday, March 11, 2019

Overarching Metanarratives

Filed under: General — Tags: — m759 @ 4:15 am

See also "Overarching + Tesseract" in this  journal. From the results
of that search, some context for the "inscape" of the previous post —

Anticommuting Dirac matrices as spreads of projective lines

Ron Shaw on the 15 lines of the classical generalized quadrangle W(2), a general linear complex in PG(3,2)

Saturday, December 23, 2017

The Right Stuff

Filed under: G-Notes,General,Geometry — Tags: — m759 @ 1:12 pm

A figure related to the general connecting theorem  of Koen Thas —

Anticommuting Dirac matrices as spreads of projective lines

Ron Shaw on the 15 lines of the classical generalized quadrangle W(2), a general linear complex in PG(3,2)

See also posts tagged Dirac and Geometry in this  journal.

Those who prefer narrative to mathematics may, if they so fancy, call
the above Thas connecting theorem a "quantum tesseract theorem ."

Sunday, December 10, 2017

Geometry

Google search result for Plato + Statesman + interlacing + interweaving

See also Symplectic in this journal.

From Gotay and Isenberg, “The Symplectization of Science,”
Gazette des Mathématiciens  54, 59-79 (1992):

“… what is the origin of the unusual name ‘symplectic’? ….
Its mathematical usage is due to Hermann Weyl who,
in an effort to avoid a certain semantic confusion, renamed
the then obscure ‘line complex group’ the ‘symplectic group.’
… the adjective ‘symplectic’ means ‘plaited together’ or ‘woven.’
This is wonderfully apt….”

IMAGE- A symplectic structure -- i.e. a structure that is symplectic (meaning plaited or woven)

The above symplectic  figure appears in remarks on
the diamond-theorem correlation in the webpage
Rosenhain and Göpel Tetrads in PG(3,2). See also
related remarks on the notion of  linear  (or line ) complex
in the finite projective space PG(3,2) —

Anticommuting Dirac matrices as spreads of projective lines

Ron Shaw on the 15 lines of the classical generalized quadrangle W(2), a general linear complex in PG(3,2)

Wednesday, March 8, 2017

Inscapes

Filed under: General,Geometry — Tags: — m759 @ 6:42 pm

"The particulars of attention,
whether subjective or objective,
are unshackled through form,
and offered as a relational matrix …."

— Kent Johnson in a 1993 essay

Illustration

Commentary

The 16 Dirac matrices form six anticommuting sets of five matrices each (Arfken 1985, p. 214):

1. alpha_1alpha_2alpha_3alpha_4alpha_5,

2. y_1y_2y_3y_4y_5,

3. delta_1delta_2delta_3rho_1rho_2,

4. alpha_1y_1delta_1sigma_2sigma_3,

5. alpha_2y_2delta_2sigma_1sigma_3,

6. alpha_3y_3delta_3sigma_1sigma_2.

SEE ALSO:  Pauli Matrices

REFERENCES:

Arfken, G. Mathematical Methods for Physicists, 3rd ed.  Orlando, FL: Academic Press, pp. 211-217, 1985.

Berestetskii, V. B.; Lifshitz, E. M.; and Pitaevskii, L. P. "Algebra of Dirac Matrices." §22 in Quantum Electrodynamics, 2nd ed.  Oxford, England: Pergamon Press, pp. 80-84, 1982.

Bethe, H. A. and Salpeter, E. Quantum Mechanics of One- and Two-Electron Atoms.  New York: Plenum, pp. 47-48, 1977.

Bjorken, J. D. and Drell, S. D. Relativistic Quantum Mechanics.  New York: McGraw-Hill, 1964.

Dirac, P. A. M. Principles of Quantum Mechanics, 4th ed.  Oxford, England: Oxford University Press, 1982.

Goldstein, H. Classical Mechanics, 2nd ed.  Reading, MA: Addison-Wesley, p. 580, 1980.

Good, R. H. Jr. "Properties of Dirac Matrices." Rev. Mod. Phys. 27, 187-211, 1955.

Referenced on Wolfram|Alpha:  Dirac Matrices

CITE THIS AS:

Weisstein, Eric W.  "Dirac Matrices."

From MathWorld— A Wolfram Web Resource.
http://mathworld.wolfram.com/DiracMatrices.html

Tuesday, November 22, 2016

Jargon

Filed under: General,Geometry — Tags: , , , — m759 @ 4:00 pm

See "sacerdotal jargon" in this journal.

For those who prefer scientific  jargon —

"… open its reading to
combinational possibilities
outside its larger narrative flow.
The particulars of attention,
whether subjective or objective,
are unshackled through form,
and offered as a relational matrix …."

— Kent Johnson in a 1993 essay

For some science that is not just jargon, see

and, also from posts tagged Dirac and Geometry

Anticommuting Dirac matrices as spreads of projective lines

The above line complex also illustrates an outer automorphism
of the symmetric group S6. See last Thursday's post "Rotman and
the Outer Automorphism
."

Tuesday, July 12, 2016

Group Elements and Skew Lines

Filed under: General,Geometry — Tags: — m759 @ 12:00 am

The following passage by Igor Dolgachev (Good Friday, 2003
seems somewhat relevant (via its connection to Kummer's 166 )
to previous remarks here on Dirac matrices and geometry

Note related remarks from E. M. Bruins in 1959 —

First page of 'Configurations in Quantum Mechanics,' by E.M. Bruins, 1959

Friday, June 3, 2016

Bruins and van Dam

Filed under: General,Geometry — Tags: , — m759 @ 8:00 am

A review of some recent posts on Dirac and geometry,
each of which mentions the late physicist Hendrik van Dam:

The first of these posts mentions the work of E. M. Bruins.
Some earlier posts that cite Bruins:

Tuesday, May 24, 2016

Rosenhain and Göpel Revisited

The authors Taormina and Wendland in the previous post
discussed some mathematics they apparently did not know was
related to a classic 1905 book by R. W. H. T. Hudson, Kummer's
Quartic Surface
.

"This famous book is a prototype for the possibility
of explaining and exploring a many-faceted topic of
research, without focussing on general definitions,
formal techniques, or even fancy machinery. In this
regard, the book still stands as a highly recommendable,
unparalleled introduction to Kummer surfaces, as a
permanent source of inspiration and, last but not least,
as an everlasting symbol of mathematical culture."

— Werner Kleinert, Mathematical Reviews ,
     as quoted at Amazon.com

Some 4×4 diagrams from that book are highly relevant to the
discussion by Taormina and Wendland of the 4×4 squares within
the 1974 Miracle Octad Generator of R. T. Curtis that were later,
in 1987, described by Curtis as pictures of the vector 4-space over
the two-element Galois field GF(2).

Hudson did not think of his 4×4 diagrams as illustrating a vector space,
but he did use them to picture certain subsets of the 16 cells in each
diagram that he called Rosenhain and Göpel tetrads .

Some related work of my own (click images for related posts)—

Rosenhain tetrads as 20 of the 35 projective lines in PG(3,2)

IMAGE- Desargues's theorem in light of Galois geometry

Göpel tetrads as 15 of the 35 projective lines in PG(3,2)

Anticommuting Dirac matrices as spreads of projective lines

Related terminology describing the Göpel tetrads above

Ron Shaw on symplectic geometry and a linear complex in PG(3,2)

Sunday, August 3, 2008

Sunday August 3, 2008

Filed under: General,Geometry — Tags: , , , — m759 @ 3:00 pm
Kindergarten
Geometry

Preview of a Tom Stoppard play presented at Town Hall in Manhattan on March 14, 2008 (Pi Day and Einstein’s birthday):

The play’s title, “Every Good Boy Deserves Favour,” is a mnemonic for the notes of the treble clef EGBDF.

The place, Town Hall, West 43rd Street. The time, 8 p.m., Friday, March 14. One single performance only, to the tinkle– or the clang?– of a triangle. Echoing perhaps the clang-clack of Warsaw Pact tanks muscling into Prague in August 1968.

The “u” in favour is the British way, the Stoppard way, “EGBDF” being “a Play for Actors and Orchestra” by Tom Stoppard (words) and André Previn (music).

And what a play!– as luminescent as always where Stoppard is concerned. The music component of the one-nighter at Town Hall– a showcase for the Boston University College of Fine Arts– is by a 47-piece live orchestra, the significant instrument being, well, a triangle.

When, in 1974, André Previn, then principal conductor of the London Symphony, invited Stoppard “to write something which had the need of a live full-time orchestra onstage,” the 36-year-old playwright jumped at the chance.

One hitch: Stoppard at the time knew “very little about ‘serious’ music… My qualifications for writing about an orchestra,” he says in his introduction to the 1978 Grove Press edition of “EGBDF,” “amounted to a spell as a triangle player in a kindergarten percussion band.”

Jerry Tallmer in The Villager, March 12-18, 2008

Review of the same play as presented at Chautauqua Institution on July 24, 2008:

“Stoppard’s modus operandi– to teasingly introduce numerous clever tidbits designed to challenge the audience.”

Jane Vranish, Pittsburgh Post-Gazette, Saturday, August 2, 2008

“The leader of the band is tired
And his eyes are growing old
But his blood runs through
My instrument
And his song is in my soul.”

— Dan Fogelberg

“He’s watching us all the time.”

Lucia Joyce



Finnegans Wake,
Book II, Episode 2, pp. 296-297:

I’ll make you to see figuratleavely the whome of your eternal geomater. And if you flung her headdress on her from under her highlows you’d wheeze whyse Salmonson set his seel on a hexengown.1 Hissss!, Arrah, go on! Fin for fun!

1 The chape of Doña Speranza of the Nacion.



Log 24, Sept. 3, 2003:
Reciprocity
From my entry of Sept. 1, 2003:

“…the principle of taking and giving, of learning and teaching, of listening and storytelling, in a word: of reciprocity….

… E. M. Forster famously advised his readers, ‘Only connect.’ ‘Reciprocity’ would be Michael Kruger’s succinct philosophy, with all that the word implies.”

— William Boyd, review of Himmelfarb, a novel by Michael Kruger, in The New York Times Book Review, October 30, 1994

Last year’s entry on this date:



Today’s birthday:
James Joseph Sylvester

Mathematics is the music of reason.”
— J. J. Sylvester

Sylvester, a nineteenth-century mathematician, coined the phrase “synthematic totals” to describe some structures based on 6-element sets that R. T. Curtis has called “rather unwieldy objects.” See Curtis’s abstract, Symmetric Generation of Finite Groups, John Baez’s essay, Some Thoughts on the Number 6, and my website, Diamond Theory.



The picture above is of the complete graph K6 …  Six points with an edge connecting every pair of points… Fifteen edges in all.

Diamond theory describes how the 15 two-element subsets of a six-element set (represented by edges in the picture above) may be arranged as 15 of the 16 parts of a 4×4 array, and how such an array relates to group-theoretic concepts, including Sylvester’s synthematic totals as they relate to constructions of the Mathieu group M24.

If diamond theory illustrates any general philosophical principle, it is probably the interplay of opposites….  “Reciprocity” in the sense of Lao Tzu.  See

Reciprocity and Reversal in Lao Tzu.

For a sense of “reciprocity” more closely related to Michael Kruger’s alleged philosophy, see the Confucian concept of Shu (Analects 15:23 or 24) described in

Shu: Reciprocity.

Kruger’s novel is in part about a Jew: the quintessential Jewish symbol, the star of David, embedded in the K6 graph above, expresses the reciprocity of male and female, as my May 2003 archives illustrate.  The star of David also appears as part of a graphic design for cubes that illustrate the concepts of diamond theory:

Click on the design for details.

Those who prefer a Jewish approach to physics can find the star of David, in the form of K6, applied to the sixteen 4×4 Dirac matrices, in

A Graphical Representation
of the Dirac Algebra
.

The star of David also appears, if only as a heuristic arrangement, in a note that shows generating partitions of the affine group on 64 points arranged in two opposing triplets.

Having thus, as the New York Times advises, paid tribute to a Jewish symbol, we may note, in closing, a much more sophisticated and subtle concept of reciprocity due to Euler, Legendre, and Gauss.  See

The Jewel of Arithmetic and


FinnegansWiki:

Salmonson set his seel:

“Finn MacCool ate the Salmon of Knowledge.”

Wikipedia:

George Salmon spent his boyhood in Cork City, Ireland. His father was a linen merchant. He graduated from Trinity College Dublin at the age of 19 with exceptionally high honours in mathematics. In 1841 at age 21 he was appointed to a position in the mathematics department at Trinity College Dublin. In 1845 he was appointed concurrently to a position in the theology department at Trinity College Dublin, having been confirmed in that year as an Anglican priest.”

Related material:

Kindergarten Theology,

Kindergarten Relativity,

Arrangements for
56 Triangles
.

For more on the
arrangement of
triangles discussed
in Finnegans Wake,
see Log24 on Pi Day,
March 14, 2008.

Happy birthday,
Martin Sheen.

Wednesday, September 3, 2003

Wednesday September 3, 2003

Filed under: General,Geometry — Tags: , , , — m759 @ 3:00 pm

Reciprocity

From my entry of Sept. 1, 2003:

"…the principle of taking and giving, of learning and teaching, of listening and storytelling, in a word: of reciprocity….

… E. M. Forster famously advised his readers, 'Only connect.' 'Reciprocity' would be Michael Kruger's succinct philosophy, with all that the word implies."

— William Boyd, review of Himmelfarb, New York Times Book Review, October 30, 1994

Last year's entry on this date:

Today's birthday:
James Joseph Sylvester

"Mathematics is the music of reason."
— J. J. Sylvester

Sylvester, a nineteenth-century mathematician, coined the phrase "synthematic totals" to describe some structures based on 6-element sets that R. T. Curtis has called "rather unwieldy objects." See Curtis's abstract, Symmetric Generation of Finite Groups, John Baez's essay, Some Thoughts on the Number 6, and my website, Diamond Theory.

The picture above is of the complete graph K6  Six points with an edge connecting every pair of points… Fifteen edges in all.

Diamond theory describes how the 15 two-element subsets of a six-element set (represented by edges in the picture above) may be arranged as 15 of the 16 parts of a 4×4 array, and how such an array relates to group-theoretic concepts, including Sylvester's synthematic totals as they relate to constructions of the Mathieu group M24.

If diamond theory illustrates any general philosophical principle, it is probably the interplay of opposites….  "Reciprocity" in the sense of Lao Tzu.  See

Reciprocity and Reversal in Lao Tzu.

For a sense of "reciprocity" more closely related to Michael Kruger's alleged philosophy, see the Confucian concept of Shu (Analects 15:23 or 24) described in

Shu: Reciprocity.

Kruger's novel is in part about a Jew: the quintessential Jewish symbol, the star of David, embedded in the K6 graph above, expresses the reciprocity of male and female, as my May 2003 archives illustrate.  The star of David also appears as part of a graphic design for cubes that illustrate the concepts of diamond theory:

Click on the design for details.

Those who prefer a Jewish approach to physics can find the star of David, in the form of K6, applied to the sixteen 4×4 Dirac matrices, in

A Graphical Representation
of the Dirac Algebra
.

The star of David also appears, if only as a heuristic arrangement, in a note that shows generating partitions of the affine group on 64 points arranged in two opposing triplets.

Having thus, as the New York Times advises, paid tribute to a Jewish symbol, we may note, in closing, a much more sophisticated and subtle concept of reciprocity due to Euler, Legendre, and Gauss.  See

The Jewel of Arithmetic and

The Golden Theorem.

Thursday, December 5, 2002

Thursday December 5, 2002

Sacerdotal Jargon

From the website

Abstracts and Preprints in Clifford Algebra [1996, Oct 8]:

Paper:  clf-alg/good9601
From:  David M. Goodmanson
Address:  2725 68th Avenue S.E., Mercer Island, Washington 98040

Title:  A graphical representation of the Dirac Algebra

Abstract:  The elements of the Dirac algebra are represented by sixteen 4×4 gamma matrices, each pair of which either commute or anticommute. This paper demonstrates a correspondence between the gamma matrices and the complete graph on six points, a correspondence that provides a visual picture of the structure of the Dirac algebra.  The graph shows all commutation and anticommutation relations, and can be used to illustrate the structure of subalgebras and equivalence classes and the effect of similarity transformations….

Published:  Am. J. Phys. 64, 870-880 (1996)


The following is a picture of K6, the complete graph on six points.  It may be used to illustrate various concepts in finite geometry as well as the properties of Dirac matrices described above.

The complete graph on a six-set


From
"The Relations between Poetry and Painting,"
by Wallace Stevens:

"The theory of poetry, that is to say, the total of the theories of poetry, often seems to become in time a mystical theology or, more simply, a mystique. The reason for this must by now be clear. The reason is the same reason why the pictures in a museum of modern art often seem to become in time a mystical aesthetic, a prodigious search of appearance, as if to find a way of saying and of establishing that all things, whether below or above appearance, are one and that it is only through reality, in which they are reflected or, it may be, joined together, that we can reach them. Under such stress, reality changes from substance to subtlety, a subtlety in which it was natural for Cézanne to say: 'I see planes bestriding each other and sometimes straight lines seem to me to fall' or 'Planes in color. . . . The colored area where shimmer the souls of the planes, in the blaze of the kindled prism, the meeting of planes in the sunlight.' The conversion of our Lumpenwelt went far beyond this. It was from the point of view of another subtlety that Klee could write: 'But he is one chosen that today comes near to the secret places where original law fosters all evolution. And what artist would not establish himself there where the organic center of all movement in time and space—which he calls the mind or heart of creation— determines every function.' Conceding that this sounds a bit like sacerdotal jargon, that is not too much to allow to those that have helped to create a new reality, a modern reality, since what has been created is nothing less."

Sunday, February 19, 2023

Hoarding Space

Filed under: General — Tags: , — m759 @ 1:53 pm

See also the star of the previous post in . . .

Quantum Tesseract Theorem .

Monday, October 21, 2019

Algebra and Space… Illustrated.

Filed under: General — Tags: , — m759 @ 4:26 pm

Related entertainment —

Detail:

   George Steiner

"Perhaps an insane conceit."



Perhaps.



See Quantum Tesseract Theorem .



Perhaps Not.



 See Dirac and Geometry .

Friday, November 27, 2015

Einstein and Geometry

Filed under: General,Geometry — Tags: , — m759 @ 2:01 pm

(A Prequel to Dirac and Geometry)

"So Einstein went back to the blackboard.
And on Nov. 25, 1915, he set down
the equation that rules the universe.
As compact and mysterious as a Viking rune,
it describes space-time as a kind of sagging mattress…."

— Dennis Overbye in The New York Times  online,
     November 24, 2015

Some pure  mathematics I prefer to the sagging Viking mattress —

Readings closely related to the above passage —

Thomas Hawkins, "From General Relativity to Group Representations:
the Background to Weyl's Papers of 1925-26
," in Matériaux pour
l'histoire des mathématiques au XXe siècle:
Actes du colloque
à la mémoire de Jean Dieudonné
, Nice, 1996  (Soc. Math.
de France, Paris, 1998), pp. 69-100.

The 19th-century algebraic theory of invariants is discussed
as what Weitzenböck called a guide "through the thicket
of formulas of general relativity."

Wallace Givens, "Tensor Coordinates of Linear Spaces," in
Annals of Mathematics  Second Series, Vol. 38, No. 2, April 1937,
pp. 355-385.

Tensors (also used by Einstein in 1915) are related to
the theory of line complexes in three-dimensional
projective space and to the matrices used by Dirac
in his 1928 work on quantum mechanics.

For those who prefer metaphors to mathematics —

"We acknowledge a theorem's beauty
when we see how the theorem 'fits' in its place,
how it sheds light around itself, like a Lichtung ,
a clearing in the woods."
— Gian-Carlo Rota, Indiscrete Thoughts ,
Birkhäuser Boston, 1997, page 132

Rota fails to cite the source of his metaphor.
It is Heidegger's 1964 essay, "The End of Philosophy
and the Task of Thinking" —

"The forest clearing [ Lichtung ] is experienced
in contrast to dense forest, called Dickung
in our older language."
— Heidegger's Basic Writings
edited by David Farrell Krell,
Harper Collins paperback, 1993, page 441

Saturday, November 14, 2015

Space Program

Filed under: General — m759 @ 5:26 pm

A quote that appeared here on April 14, 2013

"I know what 'nothing' means." — Joan Didion

Dirac on the 4×4 matrices of an underlying nothingness —

"Corresponding to the four rows and columns,
the wave function ψ  must contain a variable
that takes on four values, in order that the matrices
shall be capable of being multiplied into it."

— P. A. M. Dirac, Principles of Quantum Mechanics,
     Fourth Edition, Oxford University Press, 1958,
     page 257

Powered by WordPress
